Jodel DC1 / D18 / D19 / D20 Series
performance
and specifications
The following
table summarizes the performance specs of
the different models:
|
Plane: |
D112 |
DC1 |
D18 |
D19 |
D20 |
|
Wing span: (m) |
8,20 |
7,40 |
7.50 |
7.50 |
7.50 |
|
Length: (m) |
6,26 |
5,65 |
5,70 |
5,70 |
5.80 |
|
Height: (m) |
|
|
|
|
1.93 |
|
Wing area: (m2) |
12,70 |
9,56 |
10 |
10 |
9.93 |
|
Cabin width: (m) |
|
|
1,0 |
1,0 |
1,12 |
|
Fuel capacity: (L) |
|
|
65 |
65 |
100 |
|
No. of seats: |
2 |
2 |
2 |
2 |
2 |
|
Engine: |
|
|
|
|
|
|
Type: |
Continental |
VW 1,6 l |
VW 1,7 l |
JPX 1,835 l |
JPX 4TX75 |
|
Power: |
65 |
52 |
58 |
70* |
85 |
|
At RPM: |
|
|
|
|
3000 |
|
Weight: |
|
|
|
|
|
|
Empty weight: (kg) |
320 |
216 |
245/255 |
244 |
250/260 |
|
Max weight: (kg) |
530 |
450 |
460 |
460 |
500 |
|
Performance: |
|
|
|
|
|
|
Max speed: (km/h) |
|
|
|
|
240/250 |
|
Cruise speed: (km/h) |
160 |
170 |
175 |
|
200/220 |
|
Climb (2p): (m/s) |
3,0 |
3,5 |
3,5 |
3-3,5 |
|
|
Range: (km) |
|
|
|
|
1500 |
|
|
