Comp Air 10

The Comp Air 10XL (above) is our ultimate load-lifter... The HUGE capacity (up to 3000 lbs. useful load) is what characterizes the Comp Air 10XL Turbine. This aircraft can seat 8 adults comfortably, with room left over for baggage or a couple children. It is ideally suited for ranchers, outfitters, fish camp operators, or anyone who needs to carry a big load. Powered by the 657 shp Walter M601D turboprop, it cruises between 175 and 200 mph TAS (depending on loading, altitude, power setting, etc). Inside cabin dimensions measure 13 feet x 5 feet with 9 feet available aft of the front seats. The Comp Air 10 features modern all-composite construction, and is available in tricycle, tailwheel, or float configuration. Numerous options are available to custom-tailor this airplane to your own specifications.

specifications

powerplant
propeller
length
height
wing span
wing area
seats
empty weight
 useful load
gross weight
fuel capacity
range		 Walter M601D turboprop, 657 shp (490 kW)
x
 31 ft 0 in
 8 ft 8 in
 36 ft 6 in
 242 ft²
up to 8
 2,750 lb
x
 5,200 lb
x
 918 miles

performance

takeoff distance, ground roll
rate of climb
max speed
cruise speed
landing distance, ground roll
 service ceiling		 x
 2,000 ft/min
 222 mph
x
x
x

limiting and recommended speeds

design manoeuvring speed (Va)
never exceed speed (Vne)
stall, power off (Vsl)
landing approach speed 		x
x
x
x

All specifications are based on manufacturer's calculations
