      Glastar








            The Glastar is a later addition to
            the Glasair range. The design is composite with metal wings and has
            excellent performance and handling qualities.

                  Let's start with
                  speed—lots of speed. With a cruise speed of better than 160
                  m.p.h. (which, incidentally, is more than one mile an hour per
                  horsepower—try that in your 182!), the GlaStar is ready to
                  tackle some serious cross-country work. Top off the optional
                  auxiliary fuel tanks, settle into the spacious cabin, and
                  knock off close to 1,000 n.m. at a stretch. Trips that would
                  be prohibitively exhausting and time consuming in a slower
                  airplane suddenly are within your reach when you pilot a
                  GlaStar. In fact, for trips of less than about 500 miles in
                  length, a GlaStar will beat the airliners when you consider
                  the time you won't spend standing in check-in lines and
                  waiting for your bags. And of course, in your GlaStar, you can
                  select any one of thousands of destinations not served by the
                  airlines. The GlaStar was designed to be a travelling machine,
                  and it delivers.

                  But wait: If
                  the GlaStar is almost as fast as some production
                  retractable-gear airplanes, does that mean it's a handful for
                  the low-time pilot? Hardly! In fact, if one aspect of the
                  GlaStar's incredible performance stands out above the others,
                  it is without a doubt the airplane's "magical" slow-speed
                  handling qualities and docile stall characteristics. Of
                  course, these qualities aren't magical at all—they're the
                  result of solid engineering and cutting-edge aerodynamic
                  advances.







                  What's the
                  bottom line for you, the pilot? In a full stall, the GlaStar
                  never loses control authority in any axis. Period. Go ahead,
                  haul the stick all the way back and hold it there. Now kick
                  the rudder, roll the airplane with the ailerons, cross control
                  it if you like. The GlaStar never departs from controlled
                  flight. And thanks to the generous Fowler flaps, the stall
                  (such as it is) occurs at a meagre 49 m.p.h. (at maximum gross
                  weight).

                  Such great
                  slow-speed controllability makes the GlaStar an amazingly safe
                  airplane. It also makes it amazingly fun to fly! Does a little
                  low-and-slow sightseeing on a warm summer evening sound
                  appealing? Well, trim your GlaStar for hands-off flight at 50
                  kts. and take advantage of its tremendous visibility as the
                  scenery drifts past at ultralight speeds. Or imagine your
                  favourite mountain airstrip—you know, that 800 ft. patch of
                  rocks and ruts with the dogleg in the middle and the big trees
                  at each end! Put your GlaStar into a 1,500 f.p.m. full-flap
                  slip at 45 knots, round out smoothly and come to an easy stop
                  with less than half the strip behind you. The GlaStar is a
                  pussycat in the hands of the neophyte, but it will bring out
                  the tiger in you as you learn to exploit its incredible
                  capabilities.

                  And what's
                  the use of flying into that wilderness strip without a big
                  load of camping gear? No use! So, load 'er up! The GlaStar's
                  cavernous baggage compartment isn't just for show. At typical
                  builder-reported empty weights, the GlaStar boasts over 700
                  lbs. of useful load. That's a lot of freeze-dried beef
                  Stroghanoff on the way in and a lot of fish on the way out!

                  What's that?
                  You want even more versatility?! OK, how 'bout convertible
                  landing gear?! Lots of kit aircraft out there are available as
                  either taildraggers or trikes, but the GlaStar is the only
                  game in town if you want to be in the woods with your
                  tundra-tired taildragger on Saturday and be teaching your kid
                  to hold the nosewheel off on Sunday. Using the same main gear
                  legs and simple "plug-and-play" installation, the GlaStar can
                  be converted from tricycle to conventional gear or back in a couple
                  of hours! Installing floats, of course, is more
                  complicated—that can take as much as an afternoon! Since the
                  GlaStar was designed from the outset as a floatplane, no
                  modifications to the airframe are required for you to go
                  splashing and dashing in and out of your favourite aquatic
                  destination. As with different kinds of wheeled gear, adding
                  floats is a simple bolt-on proposition.

                  Oh, and yes .
                  . . the GlaStar has been flown on skis, too!








               specifications



                  |   |


                125 h.p. |



                160 h.p.

                   |


                180 h.p. |






                powerplant
                propeller
                length
                height
                wing span
                wing area
                seats
                empty weight

                useful load
                gross weight
                fuel capacity
                range |


                x
                x


                22.3 ft.




                9.1 ft.



                35.0 ft.





                128.0 sq. ft.


                2



                1,200 lbs.






                760 lbs.





                1,960 lbs.




                27.6 gals.




                580 n.m.

                 |


                x
                x



                22.3 ft.





                9.1 ft.



                35.0 ft.



                x128.0 sq. ft.



                2



                1,200 lbs.






                760 lbs.






                1,960 lbs.



                x27.6 gals.


                547 n.m. |


                x
                x



                22.3 ft.





                9.1 ft.



                35.0 ft.






                128.0 sq. ft.



                2
                x1,200 lbs.






                760 lbs.






                1,960 lbs.





                27.6 gals.



                448 n.m.

                 |



            performance





                takeoff distance,
                ground roll
                rate of climb
                max speed
                cruise speed
                landing distance, ground roll


                service ceiling |

                x



                1,300 f.p.m.





                136 kts


                131 kts.
                x



                17,000 ft.

                 |


                x


                2,075 f.p.m.



                145 kts.



                x140 kts.
                x



                20,000 ft.

                 |


                x



                2,150 f.p.m.





                149 kts.



                145 kts.



                x

                     |



            limiting and recommended speeds




                design manoeuvring speed (Va)
                never exceed speed (Vne)
                stall, power off (Vsl)
                landing approach speed  |


                x
                x


                49 kts.
                x |


                x
                x


                49 kts.
                x |


                x
                x


                49 kts.
                x |


            All specifications are based on manufacturer's
            calculations
   |






             |



    |
