Mooney aircraft history, performance and specifications

Al Mooney

Al Mooney as a young man

Albert W. Mooney was born in Denver, Colorado on April 12, 1906.  In 1926, at the age of 19, he was a draftsman and assistant to the chief engineer at Alexander Aircraft in Denver. This is where the classic Curtiss OX-5 powered Eaglerock became a standard.

Later, as chief engineer at Alexander (1928-1929) he was responsible for the Bullet, an advanced, high speed, low wing monoplane. With Mooney's patented retractable landing gear, it was a mild sensation and ahead of its time.

Early in 1929, Mooney left Denver to form the Mooney Aircraft Corporation with his brother, Arthur B., in Wichita, KS. There he designed and built a more advanced low-wing monoplane, the Mooney A-1. Like the Bullet, it was designed for efficiency. Then the Depression hit the Mooney Corporation, and it closed its doors in 1931.

By 1934, Mooney was with Bellanca, where he spent a short time as chief engineer. During this time, he greatly influenced the design of the very successful Bellanca low-wing wooden wonders, a version of which is still being produced.

Then, becoming the vice president and chief engineer at Monocoupe Aircraft, he developed the Model G "Dart" and the Monocoach. The Dart was unmistakably an Al Mooney airplane, and when Culver Aircraft purchased the design, prototype and tooling for the Dart in 1938, Al followed right along with it.

During his days at Culver, Al designed the famous and fully aerobatic Cadet. With its elliptical wing and retractable landing gear, the two-seat Culver Cadet was fast and efficient. Over 350 of these high-performance aircraft had been produced by the time W.W. II erupted.

During the War, the Culver Company turned to the production of radio controlled target drones, and by the war's end had produced over 3000 of the PQ-8 (a drone version of the Cadet) and the PQ-14 (its successor) target drones. The tricycle geared, bright red PQ-14 was the direct ancestor of the Mite.

In July 1946, in partnership with C.G. Yankey and W.L. McMahon, the Mooney brothers resurrected the Mooney Aircraft Corp. Al was the general manager and chief engineer, while Art Mooney was the production manager. Bill Taylor was the sales manager and chief pilot, while Yankey financed the operation. Their first offering was the Mooney Series18, an all-wood single-seater with retractable tricycle gear and a cantilevered, laminar flow wing. Test flights continued through 1947 and certification was received in July, 1948. With its now-famous "backward" tail, the Mooney "Mite" hit the sport aviation world with a price tag of less than $2000, and represented the cheapest, smallest aircraft to be produced in quantity.

The first Mites produced were certified to use the 25 h.p. liquid-cooled Crosley Cobra automobile engine. These engines were mounted back-to-front and drove the propeller through a belt-driven reduction gear. However, due to numerous technical problems, they were soon recalled and replaced, at no charge to the owners, with 65 h.p Lycomings.

The economy and efficiency of the Mite with the 65 h.p. engine was remarkable: Three-and-a-half to four gallons per hour at cruise between 120 and 130 m.p.h. This miniature "fighter plane" was cheap to buy and fun to fly. It had a lot of appeal to ex-military pilots recently returned from the War. To celebrate his 25th anniversary as an aircraft designer, Al Mooney set an unofficial distance record of 1312 miles in a Mite.One drawback of the Mite was its limited carrying capacity. The pilot could easily equal 25% of the gross weight of the airplane. In the model with the full electrical system, the baggage compartment was taken up by the battery, leaving a baggage capacity of only 40 lb.

The Mite had a hand-operated, retractable gear system which was difficult for some to operate. Pilots who had trained on other small aircraft with fixed landing gear occasionally forgot to lower the gear for landing in the Mite. This is said to have happened to an embarrassed Al Mooney while he was giving a demo flight. This incident prompted him to invent the unique Wig-wag warning device which waves from the instrument panel when the pilot throttles-back with the gear up. Mooney had confidence in the rugged little Mite. Mooney advertisements claimed that belly-landings were a quicker, safer way to stop in difficult landing situations, and would cause little damage.

There were many ingenious features in Mooney's airplane. A small Plexiglas window in the floor permitted the pilot to easily observe the nose wheel position. The Safe-Trim mechanism, operated by a small handle on the left side of the cockpit, integrated the flaps and stabilizer. Rubber disks used in the landing gear resulted in a virtually problem-free shock absorber system.

In May, 1951, during the Korean war, Mooney conceived a militarized Mite. At their own expense, they developed the M-19 "Cub-Killer", a "counter-liaison" aircraft, featuring a 90 h.p. engine with a Flottorp constant speed propeller and two .30 caliber machine guns in the wings. The gross weight was 1450 lbs. and it achieved a top speed of 150 m.p.h. Although successful strafing demonstrations were given for the US military, no purchase orders were received.

In 1953, for economic reasons Mooney moved to Kerrville, Texas, where production continued. The M-18C and M-18L, now named the Wee Scotsman, featured the 65 h.p. Continental A65-8 and the Lycoming O-145-B. However, the M-18L was soon to be discontinued because the Lycoming engines were no longer available. A plaid-coloured paint job on the vertical fin using Scotchlite reflective material made it the first plane to be reflectorized for safety. It also had a greater fuel capacity,16 gallons instead of 12, extending the range from 290 to 420 miles for Continental model, and from 355 to 465 miles for the Lycoming model. With an optional 6 gallon fuel tank installed in the wing, the range extended to 610 miles. A Flottorp controllable-pitch propeller was now available for $189. The price of a new Mite was $2840, or you could buy one for $2400 without the engine.


By 1955 the Mite had evolved into the model M-18C-55, which had a larger cockpit and canopy,  but the price was approaching $4000. Mite production came to an end in 1956, as Mooney was then devoting his talent to the development of the Mark 20 family. The four-place Mark 20, with the hallmark forward-swept tail, was another solid airplane that achieved 180 m.p.h. on 180 h.p. However, Al Mooney was soon to depart the company he had founded and move to Lockheed-Georgia. He retired in 1968 and died in Dallas, Texas on May 7, 1986 at the age of 80.
