Piper Pa38 Tomahawk history, performance and specifications

The Tomahawk (nicknamed Tommy for short) was the first all new two seat trainer built by one of the USA's big three GA manufacturers in almost three decades when it was introduced.

The PA-38-112 Tomahawk was designed as a relatively inexpensive to acquire and operate two seat trainer to tackle the firmly established definitive basic trainer in the 1970s, the Cessna 150 and 152, and to take over the spot in Piper's model range then occupied by two seat variants of the PA-28 Cherokee series.

Design input for the Tomahawk came from a questionnaire Piper distributed randomly to 10,000 flight instructors during the 1970s. With their responses in mind, Piper developed the PA-38. The resulting aircraft featured a T-tail and NASA Whitcomb GA(W)-1 design low set wing of constant chord and thickness (also featured on the competing Beech Skipper), a cabin wider than the Cherokee's (and thus much wider than the Cessna 150/152's) with 360° vision and a Lycoming O-235 powerplant. Many parts, such as the main undercarriage wheels and elevators, were interchangeable.

Piper announced the development of the Tomahawk during late 1977 and first deliveries were made in early 1978. Despite an initial mixed reaction to the new trainer from the flying public, the Tomahawk was an instant sales success with over 1000 built in the first year of production alone. In service the Tomahawk proved to be economical to operate, but the aircraft was dogged by quality control problems (some 19 Airworthiness Directives were issued by the FAA in the PA-38's first four years) and unpredictable stalling characteristics, resulting in a number of stall/spin accidents.

Flow strips were added to the wing in September 1978 to improve the much criticised stall characteristics, while a number of other problems, including the poor quality control, were addressed in the improved Tomahawk II, which was introduced for the 1981 model year. Enhancements included improved sound proofing, windscreen defrosting, door latching and nose wheel design.

Piper ceased production of the Tomahawk during 1983.   2497 Tomahawks were built between 1978 and 1983.

The aircraft has for some time been a subject of controversy. The wing apparently was redesigned with fewer ribs after the original had been certified, thus theoretically, the airplane has never been properly legal. There is a time life on the wing which can make an elderly aircraft an unattractive prospect.  Difficulties have also been experienced in spin recovery, when it has been necessary for the occupant to move as forward as possible to move the centre of gravity forward in order to recover. Nevertheless, it has been a good and rugged trained for many years. Demanding more from the trainee pilot than the Cessna 150;  many would argue that better pilots are made that way.
